During our long-term use of electric chain hoist, we must understand the scrap standard of electric hoist trolley. When the hoist trolley reaches the scrap standard, it must be scrapped in time.

The trolley of the electric hoist should be scrapped in the following situations:

The driving gear should be scrapped if one of the following situations occurs;

  1. If there is a crack or broken tooth, it needs to be scrapped;
  2. If the thickness of the gear wear reaches 30% of the original, it should be scrapped in time. If the explosion-proof electric hoist is equipped with an explosion-proof running trolley, it should be scrapped if the wear level reaches 15%.

The wheels should be scrapped in the following situations:

  1. The thickness of the wheel flange part is worn out, and the wear amount reaches 50% of the original wall, and it should be scrapped immediately;
  2. When cracks appear, they should be scrapped;
  3. The tread thickness of the running car should be scrapped if it wears more than 15% of the original thickness;
  4. The error is too high, when it exceeds 1mm, it should be scrapped.

When we regularly check the electric hoist and the trolley, we should report to the disposal immediately when we check that the equipment has reached the scrap standard. We must use a running electric chain hoist with good performance and no safety hazards to ensure safety and construction efficiency.
